DB Drive WDX8MB6

$585.00

WDX 8 Series Midbass Speaker (6.5″ 250W RMS 4 Ohm)

Category: Tags: ,

Features:

    • Copper Voice Coil Wire
    • Polyimide Coil
    • Ferrite Magnet
    • Stamped Steel Basket
    • Paper Cone Material
    • Cone Edge Cloth
    • Sold as Single
T/S PARAMETERS
Resonant Frequency (fs) 99.3Hz
D.C. Voice Coil Resistance (Re) 3.2
Mechanical Quality Factor (Qms) 10
Electrical Quality Factor (Qes) 0.54
Total Quality Factor (Qts) 0.51
Compliance Equivalent Volume (Vas) 3.9L
BL Product (BL) 8.0N/A
Diaphragm Mass inc. Airload (Mms) 17.2 gr
ADDITIONAL SPECS
Basket Diameter 6.5″ (165mm)
Max Power 400 Watts
Nominal Power 250 Watts
Impedance 4 Ω
Resonance 148.4Hz
Sensitivity 99.2
