DB Drive WDX M4
$2,807.00
IPX6 Marine Grade 4 Channel Full Range Amplifier
Features:
- 4 Channel full range class D technology
- IPX6 Marine grade conformal coated PCB
- ACT – Adaptive Crossover Technology
- CHM – Collective Heat Management
- APC – Audio Protection Circuit
- 2 ohm stereo load capability
- Bridgeable outputs @ 4ohm load
- Compatible with any 4/2 ohm loudspeaker
| GENERAL SPECIFICATIONS |
| Rated Power @ 14.4 Volts |
|
| 4 x 150 Watts @ 4Ω |
|
| 4 x 300 Watts @ 2Ω |
|
| 2 x 600 Watts @ 4Ω Bridged |
|
| SPECIFICATIONS |
| Frequency Response |
20Hz ~ 22KHz |
| Signal to Noise Ratio |
103 |
| Damping factor |
200< |
| Independent Selectable X-over |
HPF / LPF /Ful |
| Variable High/Low Pass Filter (Ch1/2) |
40Hz ~ 300Hz |
| Variable High/Low Pass Filter (Ch1/2) |
40Hz ~ 300Hz |
| Working Voltage |
12 – 15 volts |
|
| Length (A) |
10.13 in (257.3mm) |
| Width (B) |
5.25 in (133.4mm) |
| Height (C) |
2 in (50.8mm) |
