DB Drive WDX8G5.2/4

$1,761.00

8″ DVC Subwoofer – 1800W

Category: Tag:
  • 2.5″ 4 layer Anodized aluminum high temperature voice coil
  • Non-Pressed paper cone
  • Double stitched foam surround
  • Dual poly-cotton dampeners
  • Die-cast aluminum vented basket
  • Rubber gasket trim ring
  • Large gauge compression terminals
  • Protective magnet cover
PARAMETERS
Resonant Frequency (fs) 34.109Hz
D.C. Voice Coil Resistance (Re) 2 x 3.2Ω
Mechanical Quality Factor (Qms) 3.193
Electrical Quality Factor (Qes) 0.615
Total Quality Factor (Qts) 0.516
Equivalent Air Volume to Cms (Vas) 7.375 L
Mass of Diaphragm/Coil (Mms) 169.4 kg
Force Factor (Bl) 19.44
Sound Pressure Level (SPL) 78.6 dB
Structure 8″ (20.32cm) Woofer
Dynamic Power Handling 1800 Watts
Nominal Power Handling 900 Watts
Impedance Dual 2/4Ω Voice Coil
