Euphoria EXM8N

$1,294.00

8″ Neodymium Series Midrange Die-Cast Basket / 600w



Category: Tags: ,

Features

  • 2″ (51mm) Voice Coil
  • Neodymium 10 Piece Radially Equalized Magnet Assembly
  • IP52 Rated Paper Cone With Treated Cloth Surround
  • Die-Cast Aluminum Basket With Radial Venting

Specifications

Nominal Impedance 4Ω
Power Handling 300 Watts
Dynamic Wattage 600 Watts
Frequency Response 80Hz ~ 12kHz
Sensitivity (1w/1m) 99.7dB
Voice Coil Diameter 2″ (51mm)

Dimensions

Mounting Depth: 3.46″ (88mm)
Mounting Diameter: 7.09″ (180mm)
Basket Diameter: 4.33″ (110mm)

Thiele-Small Parameters

Resonant Frequency (fs) 71.3Hz
D.C. Voice Coil Resistance (Re) 3.2Ω
Mechanical Quality Factor (Qms) 3.11
Electrical Quality Factor (Qes) 0.31
Total Quality Factor (Qts) 0.28
Equivalent Air Volume to Cms (Vas) 24.8L
Mechanical Compliance (Cms) 0.37 mm/N

Driver Composition

Voice Coil Wire CCAW
Coil Polyamide
Magnet Neodymium
Basket Type Die-Cast Aluminum
Surround Edge Cloth
Cone Material Paper
