Hypnotic HEW10 Out of Stock
10″ 4Ω SINGLE VOICE COIL SUBWOOFER 900W
Features:
- 1.5″ KSV Voice Coil
- PP Cone W/ Foam Surround
- Injection Molded PP Dust Cap
- High Energy Strontium Ferrite Magnet
- Convection Vented Monolithic Forged Yoke
- Electro-plated finished Top and Bumped Bottom Plate
- CAD Optimized Electro Mechanical and Magnetic Design
- Low Stress Connecting Leads
- Poly-Cotton Spider
- Fast On Speaker Terminals
| GENERAL SPECIFICATIONS | |
|---|---|
| Structure | 10″ (25.4cm) Woofer |
| Dynamic Power Handling | 900 Watts |
| Nominal Power Handling | 450 Watts |
| Impedance | Single 4Ω Voice Coil |
| PARAMETERS | |
|---|---|
| Resonant Frequency (fs) | 31.45Hz |
| D.C. Voice Coil Resistance (Re) | 3.6Ω |
| Mechanical Quality Factor (Qms) | 7.325 |
| Electrical Quality Factor (Qes) | 0.7 |
| Total Quality Factor (Qts) | 0.639 |
| Equivalent Air Volume to Cms (Vas) | 69.2 L |
| Mass of Diaphragm/Coil (Mms) | 75.926 g |
| Force Factor (Bl) | 8.908 |
| Outside Diameter (A) | 10.11″ (257mm) |
| Cutout Diameter (B) | 9.05″ (230mm) |
| Mounting Depth (C) | 4.05″ (103mm) |
