JL Audio M103EWS-CG-WH-L&R

General Features:

• 3-Way Full Range Enclosed Speaker System (Left Side)
• Marine grade water and UV resistant design
• High performance in open air marine installations
• This system is designed for a bi-amplified application with an active crossover
  • Subwoofer driver is powered by its own amplifier (or channel), with a low-pass filter set at 80 Hz
  • The coaxial driver needs to be powered by another amplifier channel with a high-pass filter set at 80 Hz
• Color: Gloss White
• Impedance: 4 ohms

Speaker and Subwoofer Features:

• • Preloaded with:
    • 10″ JL Audio M10W5 subwoofer
      • Power Handling:
        • RMS: 250 watts
      • Injection-Molded mica-filled polypropylene cone bodies
      • Synthetic rubber surround specifically formulated with UV inhibitors
      • Marine grade progressive roll synthetic fiber spider
      • Plated marine-grade brass connection terminals
      • Specifically engineered Centrex polymer baskets are corrosion & UV-resistant
    • 7.7″ JL Audio M770-CCX Coaxial Speaker
      • Power Handling:
        • RMS: 100 watts
      • Injection-molded, mica-filled polypropylene cone with UV inhibitors
      • Synthetic rubber surround
      • 1.00″ pure silk dome tweeter
      • 1.00″ voice coil
      • Centrex® UVresistant polymer baskets and grilles
      • DMA-optimized, long excursion design
      • True 2-way networks with 1st order low-pass and 2nd order high-pass circuits

Enclosure Features:

• • Dual Chamber enclosure
    • Specifically tuned for optimal sound performance
  • Dimensions: 25.9″W x 11.96″D x 13.62″H
  • Stainless steel hardware and mounting plate provided to secure the enclosure to the mounting surface
  • A grommet is provided for exiting the speaker cables, and a solid aluminum mounting plate
