JL Audio FiX-86
July 28, 2020

JL Audio TwK-88

$3,291.00

System Tuning DSP controlled by TüN software, 8-ch. Analog & Digital Inputs / 8-ch. Analog Outputs



Category: Tags: ,
Power Supply Type Regulated DC-DC SMPS
Input Operating Voltage 10 – 16 VDC
Standby Current Draw <1.5 mA
Operating Current Draw 0.7 A
Recommended Fuse Value 1 A
Input Channels Eight
Input Type Line-level, Differential-Balanced
Input Voltage Range 250 mV – 7.1 V RMS
Minimum Input Voltage 10 mV RMS
Input Level Setting Eleven discrete selections from 250 mV – 7.1V RMS
Output Channels Eight
Analog Output Unbalanced, stereo RCA jacks
Digital Output Optical (Toslink) output (S/PDIF)
Output Impedance 450 Ω
Latency Analog – Analog: 5.425 mS
Analog – Optical: 5.470 mS
Optical – Optical: 4.860 mS
Optical – Analog: 4.805 mS
S/N Ratio 98 dB (A-Weighted, referred to 4V RMS Output)
THD+N @ Rated Output 0.02% (20 Hz – 20 kHz)
Audio Resolution 24 bit / 48 kHz
Number of EQ Bands 10 x 8 Channels
Remote Level Control Included (DRC-200)
Remote Level Functions Master Volume Control + Trim; Master Volume Control + Fader; Zone Control, LED Status Reporting
