Orion XTR 122D

General Features

• XTR Series Dual 2 ohm Subwoofer
• Power Handling:
  • MAX: 2400 watts
  • RMS: 600 watts
• Recommended power range: 300 – 600 watts RMS
• Polypropylene dust cap – moisture and UV resistant
• Oversized Nitrile-butadiene rubber surround
• Paper woofer cone
• Custom stamp steel frame
• Kapton voice coil former
• TT steel front plate
• Large ceramic magnets
• Steel back plate/pole piece T yoke assembly
• 1.125″ bottom end vent
• PVC magnet protector
• High temperature copper dual voice coil
• Interlaced conex spider with stitched and looped tinsel leads
• PVC trim ring decor
• Spring loaded push terminals
• Frequency response: 20 – 250 Hz
• Sensitivity: 87.38 dB
• Xmax: 12.075 mm
• Top-Mount Depth: 6.22″
• Cutout Diameter: 10.91″
• Driver Displacement: 0.077 ft³
• Recommended sealed enclosure: 1.50 ft³
• Recommended ported enclosure: 1.50 ft³
