Panamax MR5100

The Panamax MR5100 will protect even elaborate audio/video systems from damaging power spikes as well as the minor day-to-day current fluctuations.

Product highlights:

• total of 11 surge-protected, noise-filtered AC outlets — 10 rear, 1 front:
  • one isolated bank of four always-on outlets with two-stage noise filtering
  • one isolated bank of four high-current outlets with delayed on/off
  • one isolated bank of two switched outlets
  • one front-panel always-on convenience outlet
• front-panel USB charger port for Apple® and Android® smartphones, or other USB-equipped devices
• Automatic Voltage Monitoring (AVM) technology continuously monitors incoming AC power to protect against over- and under-voltage situations
• Protect or Disconnect™ technology disconnects AC power to equipment in the event of a catastrophic surge or spike
• Linear Level 4 EMI/RFI noise filtration circuitry virtually eliminates line noise
• two sets of in/out coaxial RF connections for cable/satellite/TV antenna
• one set of in/out RJ-45 LAN connections
• one set of in/out RJ-11 phone line connections
• front-panel digital voltmeter
• 2025-joule surge protection
• maximum current rating: 15 amps
• 8-ft. power cord with low-profile plug
• includes rack-mount brackets
• 17-1/16″W x 3-13/16″H x 14-1/16″D
• weight: 13.5 lbs.
