Quantum QPX2800.4
$1,311.00
4 CHANNEL STEREO AMPLIFIER / 3600 WATTS
FEATURES:
- Class A/B Circuitry
- 2 Ohm Load Stereo Capability
- Amber-Glow Logo Badge
- Audiophile Grade Components
- Speaker Short Circuit Protection
- High Efficiency Mosfet Design
- 12 dB Variable High Pass and Low Pass X-over
- Selectable: 0, 6, 12 dB/ Octive Bass Boost
- Buffered Line Output for Easy Daisy-Chaning
| GENERAL SPECIFICATIONS |
| Rated Power @ 14.4 Volts |
|
| Dynamic Power Handling |
4 X 90 Watts @ 4Ω |
| Dynamic Power Handling |
4 x 180 Watts @ 2Ω |
| Bridged |
2 x 300 Watts @ 4Ω |
| PARAMETERS |
| Ch 1-2 High Pass Crossover |
60Hz – 1.2KHz |
| Ch 3-4 High Pass Crossover |
60Hz – 1.2KHz |
| Ch 3-4 Low Pass Crossover |
50Hz – 400Hz |
| X-Over Slope |
12 dB |
| Signal to noise ratio |
>90dB |
| Bass Boost @ 45Hz |
0 – 12dB |
| Input Sensitivity |
285mV ~ 6V |
DIMENSIONS:
- Length: 13.7” / 348mm
- Width: 8.6” / 220mm
- Height: 1.96” / 50mm
