DB Drive DBT300
August 24, 2020
August 25, 2020



1500Wrms / 3000Wmax Audio System Charge Tank


Category: Tag:
Nominal Voltage 12V
20 Hr Capacity 65Ah
Burst Amps 1700A
Terminal Posts 8mm (included)
Dimensions 9.2″W x 5.5″D X 8.2″ H
Weight 44lb
Charging Current* 4A – 20A
Charging Voltage 14.4V-14.9V
Float Voltage 13.5V-13.8V

Recommended Charging Options:

  • AC Chargers: Any Quality Brand AGM- Smart & Microprocessor controlled- charger with the recommended specs above can be used.
  • Vehicle Alternator: 14V-15V.
  • RV Converter: 14V-15V.
  • Solar Panel: 100W-300W.
  • Wind Turbine: 100W-300W.
  • Charge Controller: 10A-UP.

* Warning: Do not use a charger with smaller amperage than the recommended Charging Current shown above.
Maintainers should ONLY be used to maintain a fully charged battery but NEVER as a charger.

Operating Temperature Range:

  • Discharge: -4~140F
  • Charge:     14~140F
  • Storage:     -4~140F

Temperature Compensation:

  • Cycle use:     -30mV/C
  • Standby use: -20mV/C
